Toro 74292 - Stopping the Machine

Figure15
1.Motioncontrol
lever-neutrallockposition
3.Forward
2.Centerun-lockposition
4.Backward
DrivingBackward
1.Movetheleverstothecenter,un-lockedposition.
2.Togobackward,slowlypullthemotioncontrol
leversrearward(Figure15).
Togostraight,applyequalpressuretobothmotion
controllevers(Figure15).
Toturn,releasepressureonthemotioncontrollever
towardthedirectionyouwanttoturn(Figure15).
Tostop,pushthemotioncontrolleverstothe
neutralposition.
StoppingtheMachine
Tostopthemachine,movethetractioncontrollevers
toneutralandmovetolockedposition,disengagethe
powertakeoff(PTO),andturntheignitionkeytooff.
Settheparkingbrakewhenyouleavethemachine;refer
toSettingtheParkingBrake.Remembertoremovethe
keyfromtheignitionswitch.
Childrenorbystandersmaybeinjuredifthey
moveorattempttooperatethetractorwhileit
isunattended.
Alwaysremovetheignitionkeyandsetthe
parkingbrakewhenleavingthemachine
unattended,evenifjustforafewminutes.
AdjustingtheControlLever
Resistance
Thetopdampermountingboltcanbeadjustedto
obtainadesiredmotioncontrolleverresistance.Refer
toFigure16forthemountingoptions.
Torquetheboltto200in-lb(22.6N⋅m).
Figure16
1.Damper4.Mediumresistanceor
mediumfeel
2.Motioncontrolbracket
5.Leastresistanceorsoftest
feel
3.Mostresistanceorrmest
feel
AdjustingtheHeight-of-Cut
Theheight-of-cutisadjustedfrom1-1/2to5inch
(38to127mm)in1/4inch(6mm)incrementsby
relocatingtheclevispinintodifferentholelocations.
1.Raisetheheight-of-cutlevertothetransport
position(alsothe5inch(127mm)cuttingheight
position)(Figure17).
