Toro 74665 - Adjusting the Motion-Control Levers; Converting to Side Discharge

Adjustingthe
Motion-ControlLevers
AdjustingtheHeight
Youcanadjustthemotion-controllevershigheror
lowerformaximumcomfort(Figure10).
g027252
Figure10
AdjustingtheTilt
Youcanadjustthemotion-controlleversforwardor
rearwardforyourcomfort.
1.Loosentheupperboltholdingthecontrollever
tothecontrol-armshaft.
2.Loosenthelowerboltjustenoughtopivotthe
controlleverforwardorrearward(Figure10).
3.Tightenbothboltstosecurethecontrolleverin
thenewposition.
4.Repeattheadjustmentfortheothercontrollever.
ConvertingtoSide
Discharge
Machineswith81cm(32-inch)
MowerDecks
Themowerdeckandmowerbladesshippedwiththe
machineweredesignedforoptimummulchingand
side-dischargeperformance.
RemovingtheDischargeCoverforSide
Discharging
1.Parkthemachineonalevelsurface,disengage
theblade-controlswitch,andengagetheparking
brake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Removethewingnutandboltsecuringthe
coverinplace(Figure11).
Note:Retainallofthepartsforfutureuse.
g004582
Figure11
1.Grassdeector
4.Hingepin
2.Dischargecover5.Wingnut
3.Lowerlip
4.Removethehingepinsecuringthecovertothe
deck(Figure11).
5.Liftthecoveroutandawayfromthedeck.
6.Lowerthegrassdeectoroverthedischarge
opening.
Important:Ensurethatthemowerhas
ahingedgrassdeectorthatdisperses
clippingstothesideanddowntowardthe
turfwhileinside-dischargemode.
16
