g294196
Figure68
1.Woodblock—6.6cm
(2-5/8inches)thick
2.Woodblock—7.3cm
(2-7/8inches)thick
6.Removethehairpincotterandwasherfromthe
lowerlift-armpin(Figure69).
g294197
Figure69
1.Height-of-cutplate
3.Washer
2.Hairpincotter
7.Rotatetheheight-of-cutplatetoadifferenthole
sothatitsupportstheweightofthemowerdeck
afteryouinstalltheplate(Figure70).
g294195
Figure70
8.Installthewasherandhairpincotter(Figure70).
9.Repeatsteps6through8fortheothersideof
themachine.
10.Checktheside-to-sidelevelagain;repeatthis
procedureuntilthemeasurementsarecorrect.
11.Continuelevelingthemowerdeckbychecking
thefront-to-rearbladeslope;refertoAdjusting
theFront-to-RearBladeSlope(page46).
AdjustingtheFront-to-RearBlade
Slope
1.Rotatetheadjustmentnutinthefrontofthe
mower(Figure71).
g294471
Figure71
1.Adjustingrod3.Adjustmentnut
2.Adjustingblock
2.T oraisethefrontofthemowerdeck,tightenthe
adjustmentnut.
