Toro 74882 - Removing the Mower

G009806
1
2
3
4
5
Figure63
1.Springremovaltool(T oro
partno.92-5771)
4.Idlerarm
2.Idlerspring5.Mowerbelt
3.Deckpost
7.Lowerthemowertothelowestheight-of-cut.
8.Placetheheight-of-cutpininthelockpositionfor
lowestheight-of-cut.
9.Removethebeltfromthemowerdeckpulleysand
removetheexistingbelt.
InstallingtheMowerBelt
1.Installthenewbeltaroundthemowerpulleysandthe
clutchpulleyundertheengine(Figure63).
2.Usingaspringremovaltool(Toropartno.92-5771),
installtheidlerspringoverthedeckpostandplace
tensionontheidlerpulleyandmowerbelt(Figure63).
3.Ensurethatthebeltisproperlyseatedinallpulleys.
4.Installthebeltcovers(Figure64).
G024489
1
2
3
Figure64
1.Positionthebeltcoverand
ensurethetabsseat
3.Tightenthescrews
2.Pivotthebeltcoverdown
RemovingtheMower
Parkthemachineonalevelsurfaceanddisengagetheblade
controlswitch.Movethemotioncontrolleversoutwardto
theneutralposition,engageparkingbrake,stoptheengine,
removethekey,andwaitforallmovingpartstostopbefore
leavingtheoperatingposition.
Lowerthemowertothelowestheight-of-cut.Selectoneof
thefollowingproceduresdependingonthemowerdecksize
installedtocompletetheremoval.
PreparingtoRemovetheMowerDeck
1.Lowerthemowertothe76mm(3inch)height-of-cut
position.
2.Removethemowerbeltfromtheenginepulley;refer
toRemovingtheMowerBelt(page42).
