Toro 74914 - Adjusting the Anti-Scalp Rollers; Positioning the Seat

G010236
1
2
3
4
5
Figure24
1.Deckliftpedal
4.Lockposition.lowest
height-of-cut(useonlyfor
deckremoval)
2.Cutheightpin
5.Lockposition.transport
position
3.Height-of-cutpositions
UsingtheLockPositions
Thedeckcanbelockedinthehighestheight-of-cutor
transportpositionorthelowestheight-of-cutposition.
1.Pushonthedeckliftpedalwithyourfootandraise
themowerdecktothetransportposition(also
the4.5inch(114mm)cuttingheightposition)
(Figure24).
2.Removethepinfromtheheight-of-cutbracket
(Figure24).
3.Selectaholeonthelockdecalandinsertthepin
(Figure24).
4.Pushonthedeckliftpedalwithyourfootandraise
theheight-of-cutleverslightlytodisengagethe
transportlock.Lowerthedecktoslowlyuntilthe
pinmakescontactwiththelever.
AdjustingtheAnti-Scalp
Rollers
Wheneveryouchangetheheight-of-cut,itis
recommendedtoadjusttheheightoftheanti-scalp
rollers.
1.Disengagethebladecontrolswitch(PTO),move
themotioncontrolleverstotheneutrallock
positionandsettheparkingbrake.
2.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
G010233
1
2
3
4
Figure25
1.Anti-scalproller3.FlangeNut
2.Bolt4.Holespacing
PositioningtheSeat
Theseatcanmoveforwardandbackward.Positionthe
seatwhereyouhavethebestcontrolofthemachine
andaremostcomfortable.
Whilesittingintheoperator’sposition,raisetheseat
adjustmentleverslightlyandmovetheseatforwardor
backwardtothedesiredposition(Figure26).
G010016
G010232
1
Figure26
1.Adjustmentlever
22
