Figure49
1.PositiveBatteryPost
3.Red(+)ChargerLead
2.NegativeBatteryPost
4.Black(-)ChargerLead
ServicingtheFuses
Theelectricalsystemisprotectedbyfuses.Itrequires
nomaintenance,however,ifafuseblowscheckthe
component/circuitforamalfunctionorshort.
Fuses:
•Main,30amp,blade-type
•Engine,20amp,blade-type
•Openfuselocation,foraccessoryfuse(notsupplied)
1.Thefusesarelocatedonrighthandconsolenextto
theseat(Figure50).
2.Toreplacethefuses,pulloutonthefusetoremove
it.
3.Installanewfuse(Figure50).
G010340
30
25
1 2
3
G01 1396
4
Figure50
1.30amp
3.Openfuselocation(notto
exceed15A)
2.25amp4.Fuseblock
