Toro 74914 - Using the Side Discharge

deckasshowninFigure32.Removethebafe
guardandretainallfasteners.
11.Removethetwolocknuts(5/16inch)tosecuring
theweldedpostsoftherightbafetothetop
ofthemowerdeckatcenterandrightofcenter
positions(Figure33).Removetherightbafefrom
themowerdeck.
G010704
1
2
3
Figure33
1.Locknut(5/16inch)3.Weldedposts,rightbafe
2.Rightbafe
12.Installthefastenersremovedpreviouslyatthefront
holesinthedischargeplateandforwardholeinthe
deck(Figure32).
13.Locatethecutoffbafeintheloosepartsbag.
Removethefastenersattherearholesofthe
dischargeplate.Installthebafeattheside
dischargeopeningonthemowerdeck(Figure34).
Figure34
1.Carriagebolt,shipped
loose
3.Cutoffbafe,existing
2.Rearholesinthe
dischargeplate
4.Locknut,existing
14.Usethefastenersremovedtosecurethecutoff
bafetothedeck.
15.Installthebladestothedeck.RefertotheInstalling
theBladesprocedureintheMaintenancesectionfor
moreinformation.
Note:Standardcuttingbladeswillimprove
dischargeperformanceandcanobtainedfromyour
localauthorizedTorodealer.
16.InstallthemowerasdescribedintheInstallingthe
MowerprocedureintheMaintenancesectionfor
moreinformation.
UsingtheSideDischarge
Themowerhasahingedgrassdeectorthatdisperses
clippingstothesideanddowntowardtheturf.
