Toro 74914 - Changing the Seat Ride Suspension; Adjusting the Motion Control Levers

ChangingtheSeatRide
Suspension
Thenumberofseatspringscanbechangedto
maximizeridercomfort.Morespringsshouldbeused
withheavieroperatorsandonroughterrain.Fewer
springsshouldbeusedwithlighteroperatorsandwhen
mowingsmooth,wellestablishedlawns.Alwayskeep
thenumberofspringsontheleftandrightsidethe
samewhenaddingandremovingsprings.
G010484
4
4
Figure27
1.Bolt3.Nut
2.Spring
4.Additionalmountingholes
Uptovespringscanbesecuredtotheseatsupport
withanutandbolt,seeFigure27.
RefertoyourPartsManualforspringandhardware
partnumbers.
AdjustingtheMotionControl
Levers
AdjustingtheHeight
Themotioncontrolleverscanbeadjustedhigheror
lowerformaximumoperatorcomfort.
1.Removethe2boltsholdingthecontrollevertothe
controlarmshaft(Figure28).
2.Movethecontrollevertothenextsetofholes.
Securetheleverwiththe2bolts(Figure28).
Note:Thecontrolleverscanalsobeinstalledon
theoutsideofthecontrolarmshafts.
G010229
1
2
3
4
Figure28
1.Controlarmshaft3.Slotted,upperhole
2.Controllever
4.Bolt
3.Repeattheadjustmentfortheoppositecontrol
lever.
AdjustingtheTilt
Themotioncontrolleverscanbetiltedforeoraftfor
maximumoperatorcomfort.
1.Loosentheupperboltholdingthecontrolleverto
thecontrolarmshaft.
2.Loosenthelowerboltjustenoughtopivotthe
controlleverforeoraft(Figure28).Tightenboth
boltstosecurethecontrolinthenewposition.
3.Repeattheadjustmentfortheoppositecontrol
lever.
G010337
Figure29
