Toro 77281 - Page 73

g334850
Figure104
1.Adjustingscrew
3.Setthegapto22to29
mm(7/8to1-1/8inches).
2.Bracket
11.Place2blocks(seeBlockHeightandRake
Table)undertherearedgeofthecuttingdeck
skirt;1oneachsideofthecuttingdeck(Figure
105).
12.Settheheight-of-cutlevertothe76mm(3
inches)position;refertoAdjustingtheHeight
ofCut(page29).
13.Place2blocksundereachsideofthefrontedge
ofthedeck,butnotundertheanti-scalproller
bracketsorwelds.
g038090
Figure105
Bottomview
1.Block—73mm(2-7/8
inches)
2.Welds
BlockHeightandRakeTable
Deck
Size
FrontBlockHeightRake
Allmower
decks
73mm(2-7/8inches)4.8to6.4mm(3/16to1/4
inch)
14.Carefullyrotatethebladessidetoside(Figure
102).
15.Lowerthemowerdecktothe76mm(3inches)
position;refertoAdjustingtheHeightofCut
(page29).
16.Loosenthebolts(Figure106)onall4corners
andensurethatthemowerdeckissitting
securelyonall4blocks.
17.Removeanyslackfromthedeckhangersand
makesurethedeck-liftfootleverispushedback
againstthestop.
18.Tightenthe4bolts.
g412952
Figure106
1.Deck-liftarmbolts
19.Ensurethattheblockstsnuglyunderthedeck
skirtandthatallattachmentboltsaretight
20.Continuelevelingthedeckbycheckingthe
front-to-rearbladeslope.
21.Checkthebladesforlevelnessandrepeatdeck
levelingprocedureifnecessary.
22.Raisethedecktothetransportposition(127
mmor5inches).
23.Installthelift-assistspringadjustingscrew
previouslyremovedinstep10.
24.Setthegapbetweenthespringandthebracket
to22to29mm(7/8to1-1/8inches).
73
