Toro 77281TA - Adjusting the Height of Cut

AdjustingtheHeightofCut
ForMachineswithaDeck-Lift
Pedal
UsingtheTransportLock
1.Pushthedeck-liftpedalfullyforwardtolockthe
mowerdeckintheTRANSPORTposition(Figure
32).
2.Pushthedeck-liftpedalforwardandpushthe
transportlockforwardtotheUNLOCKposition,
thenslowlylowerthemowerdeck.(Figure32).
g332768
Figure32
1.LOCKposition—the
mowerdecklocksinto
thetransportposition.
3.Pushonthedeck-liftpedal
usingyourfoottoraisethe
mowerdeck.
2.UNLOCKposition—the
mowerdeckdoesnotlock
intothetransportposition.
AdjustingtheHeight-of-CutPin
Youcanadjusttheheightofcutfrom38to127mm
(1-1/2to5inches)in6mm(1/4inch)incrementsby
relocatingtheclevispinintodifferentholelocations.
1.Pushthedeck-liftpedalfullyforwardtolockthe
mowerdeckintheTRANSPORTposition(also
the127mm/5inchescuttingheightposition)as
showninFigure33.
2.Toadjust,removethepinfromtheheight-of-cut
bracket(Figure33).
3.Selectaholeintheheight-of-cutbracket
correspondingtotheheightofcutdesired,and
insertthepin(Figure33).
4.Pushthedeck-liftpedalforward,pushthe
transportlockforward,andslowlylowerthe
mowerdeck.
g332767
Figure33
1.Deck-liftpedal3.Height-of-cutpin
2.Height-of-cutbracket
4.Transport-locklever
29
