Toro 79390 User Manual

Figure19
1.Hairpincotter2.Latchrod
4
AssemblingtheBaggerTop
Partsneededforthisprocedure:
1Baggertop
1Baggerscreen
Procedure
1.Turnthebaggertopover.
2.InstallthescreenasshowninFigure20andthatit
slopesdowntowardthecollectionbags.
Note:Makesurethatthescreenssnapintoplaceand
thetabsengagethebaggertop.
G005666
1
2
3
4
Figure20
1.Baggertop
3.Screentab
2.Screen4.Slotinbaggertop
5
InstallingtheBaggerTop
Partsneededforthisprocedure:
2
Grassbag
1Upperbaggertube
Procedure
1.Installthebaggertoptothebaggerframe.
2.Rotatethebaggertoptoalignthekeyholesinthe
baggertopbracketswiththekeysinthepostsonthe
baggerframe(Figure21).
11
