Figure8
1.Locknut(3/8inch)4.Bolt(3/8x1inch)
2.Weightbracket5.Rightmountingbracket
3.Leftmountingbracket
8.Installaatweighttotheweightbracketandmoveit
rearward,ushwiththebracket(Figure9).
G014880
1
2
3
Figure9
1.Keyedcrossbar
3.Suitcaseweight
2.Flatweight
9.Installasuitcaseweightinfrontoftheatweight
(Figure9).
10.Securetheweightstotheweightbracketwitha
keyed-crossbar(Figure9).Installthebarandrotateit
90degreesdownwardtolockitinplace.
11.Afteryouinstallalltheweightsandbrackets,checkthat
allthefastenersaretight.Tightenthemasnecessary.
Important:Wheneveryouremovethebagger
attachment,remembertoremovethefrontweightsto
returntheproperstabilitytothemachine.
2
InstallingtheAttachment
Mount
Partsneededforthisprocedure:
1
Stabilizerbracket(For2015andnewermodels)
2
Carriagebolt(5/16x3/4inch)
4
Locknut(5/16inch)
2
Self-tappingscrew(5/16x3/4inch)
2
Bolt(5/16x1inch)
1
Pivotframe
2Hairpincotter
2Rod
2Washer
1Draw-bardecal
For2015andNewerModelsOnly
Note:Thestabilizerbracketisusedonlyon2015andnewer
models(Figure10).
1.Installthestabilizerbrackettotheengineguardusing2
carriagebolts(5/16x3/4inch)and2locknuts(5/16
inch)(Figure10).
7
