Figure16
1.Self-tappingscrew(5/16x
3/4inch)
2.Pivotframe
3.Attachthedraw-bardecal1.3cm(1/2inch)totheleft
oftheattachmentmount(Figure17)
Figure17
1.Drawbardecal
4.Installabent,aredendofarodintothekeyedslotin
theleftsideofthemachineframe,andmovetherod
rearwardtoseatitintheframe(Figure18).
Note:Repeatthisstepfortherightsideofthe
machine.
Figure18
Leftsideshown
1.Pivot-framehole4.Supportrod
2.Washer
5.Keyedslot(existing)
3.Hairpincotter
6.Bent,aredendofsupport
rod
5.Insertthebentendsoftherodintotheattachment
mountasshowninFigure18andsecuretheendof
eachrodwithawasherandhairpincotter.
3
InstallingtheLatchRod
Partsneededforthisprocedure:
1Latchrod
1Hairpincotter
Procedure
Installthelatchrodwithahairpincotter().
10
