Figure14

Leftsideshown

1.Pivotframehole4.Supportrod

2.Washer5.Keyedslot,existing

3.Hairpincotter

6.Bent,aredendofrod

6.Insertthebentendsoftherodsintotheattachment

mountasshowninFigure14andsecuretheendof

eachrodwithawasherandhairpincotter.

For2011through2014ModelsOnly

Note:Thestabilizerbracketisnotusedon2011through

2014models.

Note:For2011through2014models,therear-engineguard

isoptionalforthisbagger.

1.Installthepivotframetothemachineframeasshown

inFigure15.Securethepivotframetothemachine

frameusing2bolts(5/16x1inch)and2locknuts

(5/16inch).

g032814

Figure15

1.Machineframe4.Bolt(5/16x2-1/2inch)

2.Locknut(5/16inch)5.Pivotframe

3.Hole6.Rear-engineguard

(optional)

2.Securethepivotframetothebottomofthemachine

frameusing2self-tappingscrews(5/16x3/4inch)as

showninFigure16.
