Toro CM Series User Manual

Controls
Becomefamiliarwithallofthecontrolsbeforeyoustartthe
engineandoperatethemachine.
EngineSwitch
WhentheengineswitchonthecowlisintheRUNposition,
itallowstheenginetorun.Movingtheengineswitchtothe
STOPpositionshutsofftheengine.
Handwheel
Thehandwheelcontrolsthedischargingactionofthedrum.
Drum-tiltBrake
Thedrum-tiltbrakelocksthedrumintoanuprightposition
oradischargingposition.
EngineControls
1
2
3
4
5
6
7
8
G019744
Figure12
1.Recoil-starthandle5.Fuelcap
2.Fuelvalve6.Dipstick
3.Chokelever7.Oil-drainplug
4.Throttlelever
8.On/Offswitch
FuelValve
Thefuelvalve(Figure13)islocatedunderneaththechoke
lever.MovetheleverforthefuelvalvetotheONposition
beforeattemptingtostarttheengine.Whenyouhavenished
mixing,shutofftheengineandmovethefuelvalveleverto
theOFFposition.
1
2
3
G018792
Figure13
1.Fuelvalve3.Throttlelever
2.Chokelever
ChokeLever
Usethechokelever(Figure13)tostartacoldengine.Before
pullingtherecoil-starthandle,movethechokelevertothe
CLOSEDposition.Oncetheengineisrunning,movethe
chokelevertotheOPENposition.Donotusethechokeifthe
engineisalreadywarmeduporiftheairtemperatureishigh.
ThrottleLever
Thethrottlelever(Figure13)controlsthespeed(rpm)ofthe
engine.Itislocatednexttothechokelever.Itsetstheengine
speedandthereforecanincreaseanddecreasetherotation
speedofthemixingpaddles.Forbestperformance,setthis
controltotheFASTpositionwhenmixingmaterial.
EngineOn/OffSwitch
UsetheOn/Offswitch(Figure14)tostartandshutoffthe
engine.Thisswitchislocatedonthefrontoftheengine.
RotatetheOn/OffswitchtotheONpositiontostartandrun
theengine.RotatetheOn/OffswitchtotheOFFposition
toshutofftheengine.
OFF
ON
1
OFF
ON
G021 103
2
Figure14
1.Offposition2.Onposition
14
