Lubrication
LubricatingtheMachine
ServiceInterval:Monthly—Greasethetrunnionsandthe
drumspindle.
1.Cleanaroundeachgreasettingwitharagandliftthe
plasticcapoffthegreasetting(Figure41).
2.Useagreaseguntolubricatethegreasettingsofboth
trunnionsandthedrumspindlewithNo.2lithium
grease(Figure41).
3.Wipeupanyexcessgrease.
G019678
Figure41
Important:Donotlubricatethepiniongearand
ringgear.Lubricationcausesthemtocollectabrasive
materialsandacceleratewear.
EngineMaintenance
ServicingtheAirCleaner
ServiceInterval:Beforeeachuseordaily—Inspectthe
air-cleanerelements.
Every50hours—Cleantheair-cleanerelements.Clean
themmorefrequentlyindustyoperatingconditions.
Every300hours/Yearly(whichevercomes
rst)—Replacethepaperair-cleanerelement.Replace
itmorefrequentlyindustyoperatingconditions.
Important:Donotoperatetheenginewithoutthe
air-lterassembly;extremeenginedamagewilloccur.
1.Shutofftheengineandwaitforallmovingpartsto
stop.
2.Disconnectthewirefromthesparkplug;referto
DisconnectingtheSpark-plugWire(page28).
3.Removethenutthatsecuresthecover(Figure42).
