Recoil-StartHandle
Tostarttheengine,pulltherecoil-starthandle(Figure12)
quicklytoturntheengineover.Theenginecontrolsdescribed
abovemustallbesetcorrectlyfortheenginetostart.
Oil-LevelSwitch
Theoil-levelswitchislocatedinsidetheengine,anditdoes
notallowtheenginetorunintheeventtheoillevelisbelow
thesafeoperatinglimit.
Specications
Note:Specicationsanddesignaresubjecttochangewithoutnotice.
Model6800468006680076800868009
BatchCapacity
0.17m
3
(6.0ft
3
)
0.255m
3
(9.0ft
3
)
0.255m
3
(9.0ft
3
)
0.255m
3
(9.0ft
3
)
0.255m
3
(9.0ft
3
)
TotalVolume0.255m
3
(9.0ft
3
)
0.43m
3
(15.1ft
3
)
0.43m
3
(15.1ft
3
)
0.43m
3
(15.1ft
3
)
0.43m
3
(15.1ft
3
)
DrumMaterial
SteelSteelSteel
PolyethylenePolyethylene
Length198.1cm
(78inches)
213.4cm
(84inches)
215.9cm
(85inches)
215.9cm
(85inches)
213.4cm
(84inches)
Width116.8cm
(46inches)
142.2cm
(56inches)
215.9cm
(85inches)
215.9cm
(85inches)
142.2cm
(56inches)
Height147.3cm
(58inches)
165.1cm
(65inches)
180.3cm
(71inches)
180.3cm
(71inches)
165.1cm
(65inches)
Weight313kg
(690lb)
362.9kg
(800lb)
396.9kg
(875lb)
396.9kg
(875lb)
380.9kg
(837lb)
Operation
Important:Beforeoperating,checkthefuelandoil
levels,andremovedebrisfromthemachine.Ensurethat
theareaisclearofpeople.
PreparingtoTowtheMachine
Important:Ensurethatyourtowvehiclehastowing
capacityfortheweightofthemachine.
Important:UseaClass2orlargerreceiver.
Note:Ensurethatyourtowvehiclehastheappropriatehitch
totowthemachine;optionsincludea50mm(2inch)ball
hitchorapintlehitch.
Note:Ifthemachineisequippedwithatrailer-lightkit,
ensurethattheelectricalconnectorofthetowvehicleis
compatiblewiththeelectricalconnectorofthemachine.
Ifyourtowvehiclehasadifferenttypeofplug,obtainan
adapterfromanautomotivepartsstore.
1.Ensurethattheengineisshutoff,thefuelvalveisin
theOFFposition,andthedrumisempty.
2.Usingthehandwheel,positionthedrumsothatitis
pointingdowntowardtheground(Figure15).
G019806
1
2
3
Figure15
1.Drumpointingdown3.Towpoleboltedinplace
2.Drum-tiltbrakeengaged
3.Lockthedrumintopositionbypushingdownthe
drum-tilt-brakehandle(Figure16).
15
