Toro Dingo 320-D User Manual

DANGER
Theremaybeburiedpower,gas,and/ortelephone
linesintheworkarea.Shockorexplosionmay
occurifyoudigintothem.
Havethepropertyorworkareamarkedforburied
linesanddonotdiginmarkedareas.Contactyour
localmarkingserviceorutilitycompanytohavethe
propertymarked(forexample,inAustralia,call
1100forthenationwidemarkingservice).
Introduction
Thismachineisacompactutilityloaderintendedfor
useinvariousearthandmaterialsmovingactivitiesfor
landscapingandconstructionwork.Itisdesignedto
operateawidevarietyofattachmentseachofwhich
performaspecializedfunction.
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoidinjury
andproductdamage.Youareresponsibleforoperating
theproductproperlyandsafely.
YoumaycontactTorodirectlyatwww.Toro.comfor
productandaccessoryinformation,helpndinga
dealer,ortoregisteryourproduct.
Wheneveryouneedservice,genuineToroparts,or
additionalinformation,contactanAuthorizedService
DealerorToroCustomerServiceandhavethemodel
andserialnumbersofyourproductready.
Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.
G014951
1
Figure1
1.Modelandserialnumberlocation
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafetyalertsymbol
(Figure2),whichsignalsahazardthatmaycauseserious
injuryordeathifyoudonotfollowtherecommended
precautions.
Figure2
1.Safetyalertsymbol
Thismanualuses2otherwordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.
Contents
Introduction.................................................................2
Safety...........................................................................3
SafeOperatingPractices.......................................3
StabilityData........................................................7
SlopeIndicator.....................................................8
SafetyandInstructionalDecals.............................9
Setup..........................................................................12
1InstallingtheValveLever.................................12
2CheckingFluidLevels......................................12
3InstallingtheBattery........................................12
ProductOverview......................................................14
Controls.............................................................14
Specications.....................................................17
Attachments/Accessories...................................17
Operation...................................................................18
FillingtheFuelTank...........................................18
DrainingWaterfromtheFuelFilter.....................18
CheckingtheEngineOilLevel............................19
CheckingtheEngineCoolantLevel....................19
RemovingDebrisfromtheTraction
Unit................................................................19
CheckingtheHydraulicFluidLevel.....................20
TestingtheParkingBrake...................................20
CheckingtheTirePressure.................................21
StartingtheEngine.............................................21
DrivingtheTractionUnit...................................21
StoppingtheTractionUnit/Engine....................21
©2011—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
2
Contactusatwww.Toro.com.
PrintedintheUSA.
AllRightsReserved
