InstallingtheAuxiliaryHandle
Partsneededforthisprocedure:
1Auxiliaryhandleassembly
Procedure
1.Separatetheauxiliaryhandlefromthehandleplatebyremovingthe4socketheadscrewsusingthe
providedAllenwrench(AofFigure4).
2.Lineuptheauxiliaryhandlewithauxiliaryhandleplateonthetrimmerhandle(BofFigure4).
3.Securetheauxiliaryhandletothehandleplatewiththe4socketheadscrewspreviouslyremoved(Cof
Figure4).
g357443
Figure4
