Maintenance
After each use of the trimmer , complete the following:
1. Remove the battery pack from the trimmer .
2. Wipe the trimmer clean with a damp cloth. Do not hose the trimmer
down or submerge it in water .
CAUTION
The line cutoff blade on the deector is sharp and can cut
you.
Do not use your hands to clean the deector shield and
blade.
3. Wipe or scrape clean the cutting head area any time there is an
accumulation of debris.
4. Check and tighten all fasteners. If any part is damaged or lost, repair
or replace it.
5. Brush debris away from air intake vents on the power head and the
exhaust on the motor housing to prevent the motor from overheating.
Replacing the Cutting Line
Use only 2.0 mm (0.080 inch) diameter monolament cutting line or 2.4
mm (0.095 inch) diameter twisted monolament cutting line from T oro.
1. Remove the battery pack from the trimmer .
2. Remove any existing line on the spool by repetitively pressing the
bump head while pulling the line out equally from both sides of the
bump head.
3. Cut a piece of line that is no longer than 7.3 m (24 ft).
Important: Do not overload the spool.
Important: Do not use any other gauge or type of line, as this
could damage the trimmer .
4. Press and turn the bump head in the direction shown by the arrows
(clockwise) on the bottom of the bump head until the marks on the
side of the bump head align with the marks beneath the eyelets
( Figure 20 ).
