Toro GrandStand 74505 User Manual

ChargingtheBattery
WARNING
Chargingthebatteryproducesgassesthatcan
explode.
Neversmokenearthebatteryandkeepsparksand
amesawayfrombattery.
Important:Alwayskeepthebatteryfullycharged
(1.265specicgravity)topreventbatterydamagewhen
thetemperatureisbelow0°C(32°F).
1.Removethebatteryfromthechassis;refertoRemoving
theBattery(page36).
2.Checktheelectrolytelevel.
3.Ensurethatthellercapsareinstalledonthebattery.
4.Chargethebatteryfor1hourat25to30Aor6hours
at4to6A.
5.Whenthebatteryisfullycharged,unplugthecharger
fromtheelectricaloutlet,anddisconnectthecharger
leadsfromthebatteryposts(Figure49).
6.Installthebatteryontothemachineandconnectthe
batterycables;refertoInstallingtheBattery(page37).
Note:Donotrunthemachinewiththebattery
disconnected;electricaldamagemayoccur.
Figure49
1.Positivebatterypost
3.Red(+)chargerlead
2.Negativebatterypost
4.Black(-)chargerlead
ServicingtheFuses
Theelectricalsystemisprotectedbyfusesandrequiresno
maintenance.Ifafuseblows,checkthecomponentorcircuit
foramalfunctionorshort.
1.Releasethecushionfromtherearofthemachine.
2.Pulloutthefusetoremoveorreplaceit(Figure50).
3.Installthecushiontotherearofthemachine.
Note:Ensurethatthecorrect-sizefuseisinstalled
Figure50.
Figure50
1.Ignitionfuse—15A3.Powertakeoff(PTO)
fuse—10A
2.Accessory-portfuse—15
A
4.Infocenterfuse—7.5A
