Toro GrandStand Mulching Kit - Installing the Kicker Fittings

5
InstallingtheKickerFittings
Partsneededforthisprocedure:
2
Kickertting
4
Carriagebolt(3/8x1inch)
4
Flangelocknut(3/8inch)
Procedure
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
1.Attherightsideofthemowerdeck,alignthe
slotsinthekickerttingwiththe2holes10mm
(3/8inch)thatyoudrilledintothemowerdeck
(Figure5).
g283725
g283726
Figure5
1.Flangelocknut(3/8inch)4.Carriagebolt(3/8x1inch)
2.10mm(3/8inch)hole
(mowerdeck)
5.Frontofthemachine
3.Kickertting
2.Assemblethekickerttingtothedeck(Figure5)
with2carriagebolts(3/8x1inch)and2ange
locknuts(3/8inch).
3.Torquetheangelocknutsto37to45N∙m(27
to33ft-lb).
4.Attheleftsideofthemowerdeck,alignthe
slotsinthekickerttingwiththe2holes10mm
(3/8inch)thatyoudrilledintothemowerdeck
(Figure6).
g283727
g283728
Figure6
1.Flangelocknut(3/8inch)4.Carriagebolt(3/8x1inch)
2.10mm(3/8inch)hole
(mowerdeck)
5.Frontofthemachine
3.Kickertting
5.Repeatsteps2and3fortheleftkickertting.
