17
Carburetor Exploded View
.
O-ring
Exchange
Jet
Choke Lever
Choke Plate
Throttle Shaft
Stop Screw
Main Jet
Nozzle
Needle and Asm.
Float
Gasket
Pin
Float Bowl
Drain Screw
7 ft-lbs (10 Nm)
Gasket
3
