PreparingtheNewSeat
Models31657and31659
Partsneededforthisprocedure:
1
Seatandsuspensionassembly
RemovingtheControlArmandSeatBeltfromtheSeat
1.Placetheseatandcontrolarmontoabench.
2.Removetheseatcushiontogainaccesstotheangenutsecuringthecontrolarmtotheseat(Figure16).
g344858
Figure16
