Toro LX500 Operator's Manual

11
Figure 7
NOTE: Any reference in this manual to the RIGHT or LEFT side of the tractor is observed from operator’s position.
NOTE: Hood styles vary by model.
A Systems Indicator Monitor/Hour Meter G Throttle Control
B PTO (Blade Engage) Knob H Ignition Switch Module
C
Choke Control
I Brake Pedal
D Parking Brake Button J Drive Pedal
E Shift Lever K Cruise Control Lever
F Cup Holder L Deck Lift Lever
