Toro Lynx User Manual

18
A
C
B
Nozzle/Bar/LPM #33/53 Nozzle @ 4,5 Bar #34/54 Nozzle @ 4,5 Bar
Trajectory 7° 10° 15° 20° 25° 30° 7° 10° 15° 20° 25° 30°
"A" Radius
16,5 17,1 18,0 18,9 20,1 20,7 18,6 17,7 18,3 19,2 20,4 22,6 21,3
"B" Spray Height 1,2 1,5 1,5 1,8 2,1 2,7 4,0 4,6 1,2 1,5 1,2 1,8 1,8 2,4 3,4 3,0 4,3 5,2
"C" Distance from Head 7,0 9,1 8,5 10,1 9,8 10,4 10,7 10,7 11,3 10,7 11,3 7,3 9,4 7,9 10,4 10,7 12,2 11,9 12,5 11,9 11,9 12,8
Nozzle/Bar/LPM #37/57 Nozzle @ 5,5 Bar #58 Nozzle @ 5,5 Bar
Trajectory 7° 10° 15° 20° 25° 30° 7° 10° 15° 20° 25° 30°
"A" Radius
19,8 21,9 21,0 22,6 23,8 23,5 25,0 25,3 26,2 27,1 25,6 25,9 22,9 23,5 25,3 26,5 28,0 26,8
"B" Spray Height 1,5 2,1 2,7 4,3 5,5 6,7 1,8 2,1 3,0 4,6 5,5 6,7
"C" Distance from Head 9,1 11,9 12,5 14,0 15,2 14,0 11,6 12,2 13,1 14,3 15,8 14,6
835S/855S Trajectory Performance—(Metric)
Nozzle/Bar/LPM #31/51 Nozzle @ 4,5 Bar #32/52 Nozzle @ 4,5 Bar
Trajectory 7° 10° 15° 20° 25° 30° 7° 10° 15° 20° 25° 30°
"A" Radius
14,0 14,0 15,2 15,5 16,2 16,5 15,2 14,0 14,9 14,9 15,2 15,5 16,8 19,2 19,5 16,5 19,8
"B" Spray Height 1,2 1,2 1,5 1,8 2,4 3,0 3,4 4,0 4,0 4,6 0,9 1,2 1,2 1,8 2,7 3,7 3,4 4,6 4,0
"C" Distance from Head 7,6 7,9 7,6 8,2 7,9 9,8 10,1 11,6 10,1 12,2 10,1 12,4 6,1 6,7 7,3 7,9 8,5 9,4 10,4 10,7 10,4 10,4 9,1
Nozzle/Bar/LPM #59 Nozzle @ 5,5 Bar
Trajectory 7° 10° 15° 20° 25° 30°
"A" Radius
23,5 23,8 25,6 27,1 29,3 28,0
"B" Spray Height 2,1 2,4 3,4 4,9 6,4 7,6
"C" Distance from Head 12,8 13,4 13,7 14,3 16,2 14,9
Information is for reference only, Actual results may vary,
Nozzle/Bar/LPM #35/55 Nozzle @ 4,5 Bar #36/56 Nozzle @ 5,5 Bar
Trajectory 7° 10° 15° 20° 25° 30° 7° 10° 15° 20° 25° 30°
"A" Radius
18,0 18,6 18,9 19,5 20,1 21,3 23,2 22,6 23,5 19,5 21,9 20,7 22,2 23,2 22,9 24,4 25,0 25,6 25,9 25,0
"B" Spray Height 1,2 1,8 1,5 1,8 2,1 2,7 3,4 4,6 5,2 1,5 2,1 2,7 4,3 5,2 6,7
"C" Distance from Head 9,1 10,4 9,8 11,0 11,0 13,1 13,1 13,7 13,1 13,7 13,1 13,7 7,6 11,6 12,2 13,7 14,9 13,7
Nozzle/PSI/GPM #33/53 Nozzle @ 65 psi #34/54 Nozzle @ 65 psi
Trajectory 7° 10° 15° 20° 25° 30° 7° 10° 15° 20° 25° 30°
"A" Radius 54' 56' 59' 62' 66'/68' 61' 58' 60' 63' 67' 74' 70'
"B" Spray Height 4'/5' 5'/6' 7' 9' 13' 15' 4'/5' 4'/6' 6'/8' 11'/10' 14' 17'
"C" Distance from Head 23'/30' 28'/33' 32' 34'/35' 35'/37' 35'/37' 24'/31' 26'/34' 35'/40' 39'/41' 39' 39'/42'
Nozzle/PSI/GPM #59 Nozzle @ 80 psi
Trajectory 7° 10° 15° 20° 25° 30°
"A" Radius 77' 78' 84' 89' 96' 92'
"B" Spray Height 7' 8' 11' 16' 21' 25'
"C" Distance from Head 42' 44' 45' 47' 53' 49'
Information is for reference only. Actual results may vary.
835S/855S Trajectory Performance—(U.S.)
Nozzle/PSI/GPM #31/51 Nozzle @ 65 psi #32/52 Nozzle @ 65 psi
Trajectory 7° 10° 15° 20° 25° 30° 7° 10° 15° 20° 25° 30°
"A" Radius 46' 46' 50'/51' 53' 54' 50' 46'/49' 49'/50' 51' 55' 63'/64' 54'/65'
"B" Spray Height 4' 4' 5'/6' 8'/10' 11'/13' 13'/15' 3'/4' 4' 6' 9' 12'/11' 15'/13'
"C" Distance from Head 25'/26' 25'/27' 26'/32' 33'/38' 33'/40' 33'/41' 20'/22' 24'/26' 28'/31' 34'/35' 34' 34'/30'
Nozzle/PSI/GPM #35/55 Nozzle @ 65 psi #36/56 Nozzle @ 80 psi
Trajectory 7° 10° 15° 20° 25° 30° 7° 10° 15° 20° 25° 30°
"A" Radius 59' 61'/62' 64'/66' 70' 76' 74'/77' 64'/72' 68'/73' 76'/75' 80'/82' 84'/85' 82'
"B" Spray Height 4'/6' 5'/6' 7'/9' 11' 15' 17' 5' 7' 9' 14' 17' 22'
"C" Distance from Head 30'/34' 32'/36' 36'/43' 43'/45' 43'/45' 43'/45' 25' 38' 40' 45' 49' 45'
Nozzle/PSI/GPM #37/57 Nozzle @ 80 psi #58 Nozzle @ 80 psi
Trajectory 7° 10° 15° 20° 25° 30° 7° 10° 15° 20° 25° 30°
"A" Radius 65'/72' 69'/74' 78'/77' 82'/83' 86'/89' 84'/85' 75' 77' 83' 87' 92' 88'
"B" Spray Height 5' 7' 9' 14' 18' 22' 6' 7' 10' 15' 18' 22'
"C" Distance from Head 30' 39' 41' 46' 50' 46' 38' 40' 43' 47' 52' 48'

Toro Lynx Specifications

General

Manufacturer	Toro
Flow Management	Yes
Output Voltage	24 VAC
Communication	Wireless
Remote Control	Yes
Reporting	Yes
