Toro Lynx User Manual

21
DT 35 Performance Data − 25° - (Metric)
Front Nozzle
Positions
Nozzle Set 30
(White Plug)
Nozzle Set 31
(Yellow)
Nozzle Set 32
(Blue)
Nozzle Set 33
(Brown)
Nozzle Set 34
(Orange)
Nozzle Set 35
(Green)
Nozzle Set 36
(Gray)
Nozzle Set 37
(Black)
102-2208 102-6906 102-0726 102-6907 102-0728 102-6955 102-6935 102-6936
Yellow Biege Yellow Brown Yellow Yellow Yellow Yellow Yellow Yellow Yellow Green Green Green Green Green
102-5670 102-6942 102-5670 102-5671 102-5670 102-6884 102-5670 102-6884 102-5670 102-6884 102-5670 102-6885 102-6531 102-6885 102-6531 102-6885
Back Nozzle
Positions
Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug
102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335
Bar kPa kg/cm2 Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM
3,4 340 3,47 13,1 31,0 16,2 52,2 17,1 69,3 18,6 82,1
— — — — — — — —
4,5 450 4,59 13,7 37,9 16,2 58,7 18,0 77,6 19,5 92,4 20,7 106,7 22,0 129,1
— — — —
5,5 550 5,61 14,0 43,5 17,4 65,5 18,9 85,9 20,4 102,6 21,7 117,7 22,9 143,1 23,8 152,5 24,4 166,5
6,9 690 7,04 14,3 50,7 18,0 72,3 19,8 94,2 21,4 112,8 22,6 129,1 24,1 154,8 24,7 165,8 25,3 179,0
DT35 Series Performance Chart—15°
Bar kPa kg/cm2 Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM
3,4 340 3,47 13,1 31,0 15,9 51,5 17,7 68,5 18,6 81,4
— — — — — — — —
4,5 450 4,59 13,7 37,9 16,5 57,9 18,3 76,8 19,5 91,6 19,8 103,3 21,0 125,3
— — — —
5,5 550 5,61 14,0 43,5 17,7 65,1 19,5 85,5 21,0 101,4 21,0 114,3 22,9 139,3 23,2 150,3 23,2 162,4
6,9 690 7,04 14,3 50,7 18,3 71,9 20,1 93,5 21,7 111,7 22,0 124,5 23,8 149,5 25,0 161,2 25,0 174,5
Stator 102-6929 Blue 102-1939 Yellow 102-1940 White
Conversions DT35-3134 DT35-3537
DT 35 Performance Data − 25° - (U.S.)
Front
Nozzle
Positions
Nozzle Set 30
(White Plug)
Nozzle Set 31
(Yellow)
Nozzle Set 32
(Blue)
Nozzle Set 33
(Brown)
Nozzle Set 34
(Orange)
Nozzle Set 35
(Green)
Nozzle Set 36
(Gray)
Nozzle Set 37
(Black)
102-2208 102-6906 102-0726 102-6907 102-0728 102-6955 102-6935 102-6936
Yellow Biege Yellow Brown Yellow Yellow Yellow Yellow Yellow Yellow Yellow Green Green Green Green Green
102-5670 102-6942 102-5670 102-5671 102-5670 102-6884 102-5670 102-6884 102-5670 102-6884 102-5670 102-6885 102-6531 102-6885 102-6531 102-6885
Back Nozzle
Positions
Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug
102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335
PSI Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM
50 43 8.2 53 13.8 56 18.3 61 21.7 65 25.3 — — — — — —
65 45 10.0 53 15.5 59 20.5 64 24.4 68 28.2 72 34.1 — — — —
80 46 11.5 57 17.3 62 22.7 67 27.1 71 31.1 75 37.8 78 40.3 80 44.0
100 47 13.4 59 19.1 65 24.9 70 29.8 74 34.1 79 40.9 81 43.8 83 47.3
DT35 Series Performance Chart—15°
PSI Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM
50 43 8.2 52 13.6 58 18.1 61 21.5 62 25.6 — — — — — —
65 45 10.0 54 15.3 60 20.3 64 24.2 65 27.3 69 33.1 — — — —
80 46 11.5 58 17.2 64 22.6 69 26.8 69 30.2 75 36.8 76 39.7 76 42.9
100 47 13.4 60 19.0 66 24.7 71 29.5 72 32.9 78 39.5 82 42.6 82 46.1
Stator 102-6929 Blue 102-1939 Yellow 102-1940 White
Conversions DT35-3134 DT35-3537
■ Not recommended at these pressures.
Toro recommends the use of a 1
1
⁄4" swing joint at flows over 25-GPM (95-LPM). Sprinkler radius of throw per ASAE standard S398.1.
All sprinklers are equipped with the selectable pilot valve that allows settings at 50, 65, 80 and 100 psi.
DT35 Nozzle Apex—(U.S.)
Pressure Nozzle Apex at 15˚ Apex at 25°
65 PSI
31 6’ @ 51’ 13’ @ 54’
32 6’ @ 51’ 11’ @ 64’
33 7’ @ 59’ 13’ @ 68’
34 8’ @ 63’ 15’ @ 74’
35 9’ @ 66’ 15’ @ 76’
80 PSI
36 8’ @ 75’ 18’ @ 83’
37 9’ @ 74’ 19’ @ 82’
DT35 Nozzle Apex—(Metric)
Pressure Nozzle Apex at 15˚ Apex at 25°
4,5 bar
31 1,8m @ 15,5m 4m @ 16,4m
32 1,8m @ 15,5m 3,4m @ 19,5m
33 2,1m @ 18m 4m @ 20,7m
34 2,4m @ 19m 4,6m @ 22,6m
35 2,7m @ 20m 4,6m @ 23m
5,5 bar
36 2,4m @ 22,9m 5,5m @ 25,3m
37 2,7m @ 22,5m 5,8m @ 25m
DT35 Series
Full Circle/Part Circle Sprinklers
Note: Mainless and Back Nozzle Data Located on Page 29.
