22
DT 55 Performance Data —25° - (U.S.)
Front
Nozzle
Positions
Nozzle Set 51
(Yellow)
Nozzle Set 52
(Blue)
Nozzle Set 53
(Brown)
Nozzle Set 54
(Orange)
Nozzle Set 55
(Green)
Nozzle Set 56
(Gray)
Nozzle Set 57
(Black)
Nozzle Set 58
(Red)
Nozzle Set 59
(Beige)
102-6906 102-0726 102-6907 102-0728 102-6955 102-6935 102-6936 102-6909 102-4259
Yellow Brown Yellow Yellow Yellow Yellow Yellow Yellow Yellow Green Green Green Green Green Green Green Green Green
102-5670 102-5671 102-5670 102-6884 102-5670 102-6884 102-5670 102-6884 102-5670 02-6885 102-6531 102-6885 102-6531 102-6885 102-6531 102-6885 102-6531 102-6885
Back Nozzle
Positions
Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug
102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335
PSI Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM
50 55 14.1 57 18.5 62 22.3 66 25.8 — — — — — — — — — —
65 57 15.8 60 20.9 65 25.1 69 28.7 73 35.9 — — — — — — — —
80 59 17.5 61 23.1 68 27.8 72 31.7 76 39.7 80 43.1 83 48.2 85 50.0 89 57.5
100 61 19.3 63 25.3 71 30.3 75 34.5 80 43.5 83 49.0 88 51.5 90 53.9 92 61.3
DT55 Series Performance Chart—15°
50 55 14.0 59 16.5 62 22.2 63 25.6 — — — — — — — — — —
65 56 15.6 62 20.7 65 25.0 66 28.5 75 35.3 — — — — — — — —
80 59 17.4 66 23.0 69 27.7 70 31.5 78 39.0 78 42.4 79 46.9 79 49.5 82 57.2
100 60 19.2 68 25.1 71 30.2 72 34.3 80 41.9 81 47.2 83 52.1 83 53.4 85 60.8
Stator 102-1939 Yellow 102-1940 White 102-1941 White
Conversions DT55-5154 DT55-5558 DT55-59
■ Not recommended at these pressures.
Toro recommends the use of a 1
1
⁄4" swing joint at flows over 25-GPM (95-LPM). Sprinkler radius of throw per ASAE standard S398.1.
All sprinklers are equipped with the selectable pilot valve that allows settings at 50, 65, 80 and 100 psi.
DT 55 Performance Data - 25° - (Metric)
Front
Nozzle
Positions
Nozzle Set 51
(Yellow)
Nozzle Set 52
(Blue)
Nozzle Set 53
(Brown)
Nozzle Set 54
(Orange)
Nozzle Set 55
(Green)
Nozzle Set 56
(Gray)
Nozzle Set 57
(Black)
Nozzle Set 58
(Red)
Nozzle Set 59
(Beige)
102-6906 102-0726 102-6907 102-0728 102-6955 102-6935 102-6936 102-6909 102-4259
Yellow Brown Yellow Yellow Yellow Yellow Yellow Yellow Yellow Green Green Green Green Green Green Green Green Green
102-5670 102-5671 102-5670 102-6884 102-5670 102-6884 102-5670 102-6884 102-5670 02-6885 102-6531 102-6885 102-6531 102-6885 102-6531 102-6885 102-6531 102-6885
Back Nozzle
Positions
Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug Red Plug
102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335 102-4335
Bar kPa kg/cm2 Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM
3,4 340 3,47 16,7 53,4 17,3 70,0 18,9 84,4 20,1 97,6 — — — — — — — — — —
4,5 450 4,59 17,4 59,8 18,2 79,1 19,8 95,0 21,0 108,6 22,3 135,8 — — — — — — — —
5,5 550 5,61 18,0 66,2 18,5 87,4 20,7 105,2 21,9 119,9 23,1 150,3 24,4 163,2 25,2 182,5 25,9 189,3 27,1 217,6
6,9 690 7,04 18,6 73 19,2 95,7 21,7 114,7 22,8 130,6 24,4 164,6 25,2 185,5 26,8 194,9 27,4 204,0 28,0 232,0
DT55 Series Performance Chart—15°
Bar kPa kg/cm2 Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM
3,4 340 3,47 16,7 53,0 17,9 62,5 18,9 84,0 19,2 96,9 — — — — — — — — — —
4,5 450 4,59 17,1 59,0 18,8 78,3 19,8 94,6 20,1 107,9 22,8 133,6 — — — — — — — —
5,5 550 5,61 18,0 65,9 20,1 87,1 21,0 104,8 21,4 119,2 23,1 147,6 23,7 160,5 24,0 177,5 24,0 187,4 25,0 216,5
6,9 690 7,04 18,2 72,7 20,7 95,0 21,7 114,3 22,0 129,8 24,4 158,6 24,6 184,3 25,3 192,2 25,3 202,1 25,9 230,1
Stator 102-1939 Yellow 102-1940 White
102-1941 White
Conversions DT55-5154 DT55-5558 DT55-59
DT55 Nozzle Apex—(Metric)
Pressure Nozzle Apex at 15˚ Apex at 25°
4,5 bar
51 1,8m @ 15,5m 4m @ 16,4m
52 1,8m @ 15,5m 3,4m @ 19,5m
53 2,1m @ 18m 4m @ 20,7m
54 2,4m @ 19m 4,6m @ 22,6m
55 2,7m @ 20m 4,6m @ 23m
5,5 bar
56 2,4m @ 22,9m 5,5m @ 25,3m
57 2,7m @ 22,5m 5,8m @ 25m
58 3m @ 25m 5,5m @ 26,5m
59 3,4m @ 24,6m 6,4m @ 27,7m
DT55 Nozzle Apex—(U.S.)
Pressure Nozzle Apex at 15˚ Apex at 25°
65 PSI
51 6’ @ 51’ 13’ @ 54’
52 6’ @ 51’ 11’ @ 64’
53 7’ @ 59’ 13’ @ 68’
54 8’ @ 63’ 15’ @ 74’
55 9’ @ 66’ 15’ @ 76’
80 PSI
56 8’ @ 75’ 18’ @ 83’
57 9’ @ 74’ 19’ @ 82’
58 10’ @ 82’ 18’ @ 87’
59 11’ @ 81’ 21’ @ 91’
DT55 Series
Full Circle/Part Circle Sprinklers
