Toro Lynx - Page 26

26
835B Series Performance Chart—25° (U.S.)
Base
Pressure
Nozzle Set 30
(White)
102-2208
Nozzle Set 31
(Yellow)
102-4587
Nozzle Set 32
(Blue)
102-4588
Nozzle Set 33
(Brown)
102-4589
Nozzle Set 34
(Orange)
102-0728
Nozzle Set 35
(Green)
102-0729
Nozzle Set 36
(Gray)
102-0730
Nozzle Set 37
(Black)
102-4261
Nozzle Set 38
(Red)
102-6909
Blue Gray Blue Gray Red Gray Orange Gray Orange Gray Blue Gray Blue Gray Orange Gray Blue Gray
102-2925 102-2910 102-2925 102-2910 102-2928 102-2910 102-2926 102-2910 102-2926 102-2910 102-2925 102-2910 102-2925 102-2910 102-2926 102-2910 102-2925 102-2910
Back Nozzle 102-4335 Red Plug
psi Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM
50 42 7.1 52 14.0 58 18.0 — — — — — — — — — — — —
60 43 7.9 54 15.2 60 19.5 66 21.9 — — — — — — — — — —
70 45 8.8 55 16.4 63 21.0 68 23.6 74 32.7 77 35.2 — — — — — —
80 46 9.6 57 17.4 65 22.6 70 25.3 77 35.1 79 37.7 84 39.6 86 43.4 90 47.5
90 47 10.4 58 18.5 68 23.9 72 26.8 79 37.0 82 39.9 86 41.9 88 45.9 93 50.0
100 48 11.2 59 19.4 70 25.2 74 28.2 80 38.9 84 41.8 88 44.1 90 48.4 95 52.5
Stator 102-6929 Blue 102-1939 Yellow 102-1940 White
Conversions 835S-3134
(Requires screen replacement) 835S-3537 (Requires screen replacement)
■ Not recommended at these pressures. Radius shown in feet.
Toro recommends the use of a 1
1
⁄4" swing joint at flows over 25-GPM (95-LPM). Sprinkler radius data collected in Toro’s zero wind test facility per ASAE standard S398.1.
Actual site conditions must be considered when selecting the appropriate nozzle.
All sprinklers are equipped with the selectable pilot valve that allows settings at 50, 65, 80 and 100 psi.
835B Series Performance Chart—25° (Metric)
Base Pressure
Nozzle Set 30
(White)
102-2208
Nozzle Set 31
(Yellow)
102-4587
Nozzle Set 32
(Blue)
102-4588
Nozzle Set 33
(Brown)
102-4589
Nozzle Set 34
(Orange)
102-0728
Nozzle Set 35
(Green)
102-0729
Nozzle Set 36
(Gray)
102-0730
Nozzle Set 37
(Black)
102-4261
Nozzle Set 38
(Red)
102-6909
Blue Gray Blue Gray Red Gray Orange Gray Orange Gray Blue Gray Blue Gray Orange Gray Blue Gray
102-2925 102-2910 102-2925 102-2910 102-2928 102-2910 102-2926 102-2910 102-2926 102-2910 102-2925 102-2910 102-2925 102-2910 102-2926 102-2910 102-2925 102-2910
Back Nozzle 102-4335 Red Plug
Bar kPa kg/cm2 Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM
3,5 345 3,52 13 26,9 16 53,0 18 68,1 — — — — — — — — — — — —
4,1 414 4,22 13 30,0 16 57,5 18 73,9 20 82,9 — — — — — — — — — —
4,8 483 4,92 14 33,1 17 62,1 19 79,6 21 89,3 23 123,8 23 133,2 — — — — — —
5,5 552 5,63 14 36,3 17 65,9 20 85,5 21 95,8 23 132,9 24 142,7 26 149,9 26 164,3 27 179,8
6,2 621 6,33 14 39,4 18 70,0 21 90,5 22 101,2 24 140,0 25 151,0 26 158,6 27 173,7 28 189,3
6,9 689 7,03 15 42,4 18 73,4 21 95,4 23 106,7 24 147,2 26 158,2 27 166,9 27 183,2 29 198,7
Stator 102-6929 Blue 102-1939 Yellow 102-1940 White
Conversions 835S-3134 835S-3537
Note: Mainless and Back Nozzle Data Located on Page 29.
