27
DT35B Series Performance Chart—25° (U.S.)
Front
Nozzle
Positions
Nozzle Set 30
(White Plug)
102-2208
Nozzle Set 31
(Yellow)
102-6906
Nozzle Set 32
(Blue)
102-0726
Nozzle Set 33
(Brown)
102-6907
Nozzle Set 34
(Orange)
102-0728
Nozzle Set 35
(Green)
102-6955
Nozzle Set 36
(Gray)
102-6935
Nozzle Set 37
(Black)
102-6936
Nozzle Set 38
(Red)
102-6909
Yellow Biege Yellow Brown Yellow Yellow Yellow Yellow Yellow Yellow Yellow Green Green Green Green Green Green Green
102-5670 102-6942 102-5670 102-5671 102-5670 102-6884 102-5670 102-6884 102-5670 102-6884 102-5670 102-6885 102-6531 102-6885 102-6531 102-6885 102-6531 102-6885
Back Nozzles 102-4335 Red Plug
PSI Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM
50 43 8.2 55 13.6 56 18.3 — — — — — — — — — — — —
60 44 9.3 56 15.0 58 20.1 63 24.2 — — — — — — — — — —
70 45 10.4 58 16.2 60 21.8 65 26.3 69 30.0 73 37.0 — — — — — —
80 46 11.5 59 17.3 62 23.3 67 28.0 71 32.1 75 39.6 78 42.9 80 48.6 85 50.6
90 47 12.5 60 18.4 64 24.7 69 29.8 73 34.2 77 42.0 80 45.4 82 51.5 88 53.6
100 47 13.4 61 19.3 65 26.0 70 31.4 74 35.9 79 44.2 81 48.8 83 54.2 90 56.3
Stator 102-6929 Blue 102-1939 Yellow 102-1940 White
Conversions DT35-3134 (Requires screen replacement) DT35-3537 (Requires screen replacement)
■
Not recommended at these pressures. Radius shown in feet.
Toro recommends the use of a 1
1
⁄4" swing joint at flows over 25-GPM (95-LPM). Sprinkler radius data collected in Toro’s zero wind test facility per ASAE standard S398.1.
Actual site conditions must be considered when selecting the appropriate nozzle.
All sprinklers are equipped with the selectable pilot valve that allows settings at 50, 65, 80 and 100 psi.
DT35B Series Performance Chart—25° (Metric)
Front Nozzle
Positions
Nozzle Set 30
(White Plug)
102-2208
Nozzle Set 31
(Yellow)
102-6906
Nozzle Set 32
(Blue)
102-0726
Nozzle Set 33
(Brown)
102-6907
Nozzle Set 34
(Orange)
102-0728
Nozzle Set 35
(Green)
102-6955
Nozzle Set 36
(Gray)
102-6935
Nozzle Set 37
(Black)
102-6936
Nozzle Set 38
(Red)
102-6909
Yellow Biege Yellow Brown Yellow Yellow Yellow Yellow Yellow Yellow Yellow Green Green Green Green Green Green Green
Back Nozzle
Positions
102-5670 102-6942 102-5670 102-5671 102-5670 102-6884 102-5670 102-6884 102-5670 102-6884 102-5670 102-6885 102-6531 102-6885 102-6531 102-6885 102-6531 102-6885
Back Nozzles 102-4335 Red Plug
Bar kPa
kg/cm2
rad/m lpm rad/m lpm rad/m lpm rad/m lpm rad/m lpm rad/m lpm rad/m lpm rad/m lpm rad/m lpm
3,5 345 3,52 13 31,0 17 51,5 17 69,3
— — — — — — — — — — — —
4,1 414 4,22 13 35,2 17 56,8 18 76,1 19 91,6
— — — — — — — — — —
4,8 483 4,92 14 39,3 18 61,3 18 82,5 20 99,5 21 113,6 22 140,0
— — — — — —
5,5 552 5,63 14 43,5 18 65,5 19 88,2 20 106,0 22 121,5 23 149,9 24 162,4 24 184,0 26 191,5
6,2 621 6,33 14 47,1 18 69,6 19 93,5 21 112,8 22 129,4 23 159,0 24 171,8 25 194,9 27 202,9
6,9 689 7,03 14 50,7 19 73,1 20 98,4 21 118,8 23 135,9 24 167,3 25 184,7 25 205,1 27 213,1
Stator 102-6929 Blue 102-1939 Yellow 102-1940 White
Conversions DT35-3134 DT35-3537
B Series
DT35B Series Full Circle/Part Circle Sprinklers
Note: Mainless and Back Nozzle Data Located on Page 29.
