28
DT34B Series Performance Chart—25° (U.S.)
Front
Nozzle
Positions
Nozzle Set 31
(Yellow)
102-0725
Nozzle Set 32
(Blue)
102-7001
Nozzle Set 33
(Brown)
102-0727
Nozzle Set 34
(Orange)
102-7002
Nozzle Set 35
(Green)
102-6908
Nozzle Set 36
(Gray)
102-0730
Nozzle Set 37
(Black)
102-4261
Nozzle Set 38
(Red)
102-4260
Front Nozzles 102-4335 Red Plug
Back
Nozzle
Positions
Yellow Blue Yellow Orange Yellow Red Yellow Beige Yellow Beige Yellow Red Yellow Gray Yellow Gray
102-6937 102-2925 102-6937 102-2926 102-6937 102-2928 102-6937 102-2929 102-6937 102-2929 102-6937 102-6944 102-6937 102-6945 102-6937 102-6945
PSI Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM
50 57 13.0 58 15.5 — — — — — — — — — — — —
60 58 14.1 60 17.2 67 23.6 — — — — — — — — — —
70 59 15.5 61 18.2 69 26.2 73 30.0 78 35.7 — — — — — —
80 60 16.2 63 20.5 72 27.9 76 32.1 80 38.2 83 40.9 85 42.1 91 50.2
90 61 17.5 65 22.0 74 29.7 78 34.1 82 40.5 86 43.4 88 44.5 93 52.8
100 62 18.8 66 23.4 75 31.4 79 36.0 84 42.7 88 45.8 91 46.9 95 55.4
Stator 102-6929 Blue 102-1940 White
Conver-sions DT34-3134 (Requires screen replacement) DT34-3537 (Requires screen replacement)
■
Not recommended at these pressures. Radius shown in feet.
Toro recommends the use of a 1
1
⁄4" swing joint at flows over 25-GPM (95-LPM). Sprinkler radius data collected in Toro’s zero wind test facility per ASAE standard S398.1.
Actual site conditions must be considered when selecting the appropriate nozzle.
All sprinklers are equipped with the selectable pilot valve that allows settings at 50, 65, 80 and 100 psi.
DT34B Series Performance Chart—25° (Metric)
Front Nozzle
Positions
Nozzle Set 31
(Yellow)
102-0725
Nozzle Set 32
(Blue)
102-7001
Nozzle Set 33
(Brown)
102-0727
Nozzle Set 34
(Orange)
102-7002
Nozzle Set 35
(Green)
102-6908
Nozzle Set 36
(Gray)
102-0730
Nozzle Set 37
(Black)
102-4261
Nozzle Set 38
(Red)
102-4260
Front Nozzles 102-4335 Red Plug
Back Nozzle
Positions
Yellow Blue Yellow Orange Yellow Red Yellow Beige Yellow Beige Yellow Red Yellow Gray Yellow Gray
102-6937 102-2925 102-6937 102-2926 102-6937 102-2928 102-6937 102-2929 102-6937 102-2929 102-6937 102-6944 102-6937 102-6945 102-6937 102-6945
Bar kPa kg/cm2 rad/m lpm rad/m lpm rad/m lpm rad/m lpm rad/m lpm rad/m lpm rad/m lpm rad/m lpm
3,5 345 3,52 17 49,2 18 58,7
— — — — — — — — — — — —
4,1 414 4,22 18 53,2 18 64,9 20 89,3
— — — — — — — — — —
4,8 483 4,92 18 58,7 19 68,9 21 99,2 22 113,6 24 135,1
— — — — — —
5,5 552 5,63 18 61,3 19 77,6 22 105,6 23 121,5 24 144,6 25 154,8 26 159,3 28 190,0
6,2 621 6,33 19 66,2 20 83,1 22 112,2 24 128,9 25 153,1 26 164,1 27 168,4 28 199,8
6,9 689 7,03 19 71,2 20 88,6 23 118,8 24 136,3 26 161,6 27 173,4 28 177,5 29 209,7
Stator 102-6929 Blue 102-1940 White
Conversions DT34-3134 DT34-3537
