Toro Multi Pro 1250 - Page 35

35
1
1827
1
1888
FIG. 7
1. Universal Joint on Rear Axle
FIG. 10
1. Center Steering Pivot
FIG. 8
1. Lubrication Point on Pump
1779
1
FIG. 11
1.
Boom Hinge
LUBRICATION
FIG. 9
1. Tie Rod 2. Center Steering Pivot (Ref)
1
1
2
1887
1889
1
