Toro OSMAC Field Service Guide

1 SERIAL PORT #1
1 SERIAL DATA BITS
7 DATA BITS
8 DATA BITS
2 SERIAL PORT RATE
1 - 300 BAUD
2 - 600 BAUD
3 - 1200 BAUD
4 - 2400 BAUD
5 - 4800 BAUD
6 - 9600 BAUD
7 - 19200 BAUD
3 SERIAL STOP BITS
1 STOP BIT
2 STOP BITS
4 SERIAL PARITY
EVEN PARITY
ODD PARITY
NO PARITY
5 FLOW CONTROL
NO FLOW CONTROL
HARDWARE CONTROL
6 PORT1 PROTOCOL
1 - TAP
2 - COMP1
3 - COMP2
7 TAP TIMEOUT
8 COMP TIMEOUT
9 MANUAL TIMEOUT
2 SERIAL PORT #2
1 SERIAL DATA BITS
7 DATA BITS
8 DATA BITS
2 SERIAL PORT RATE
1 - 300 BAUD
2 - 600 BAUD
3 - 1200 BAUD
4 - 2400 BAUD
5 - 4800 BAUD
6 - 9600 BAUD
7 - 19200 BAUD
3 SERIAL STOP BITS
1 STOP BIT
2 STOP BITS
4 SERIAL PARITY
EVEN PARITY
ODD PARITY
NO PARITY
5 FLOW CONTROL
NO FLOW CONTROL
HARDWARE CONTROL
6 PORT1 PROTOCOL
1 - TAP
2 - COMP1
3 - COMP2
7 TAP TIMEOUT
8 COMP TIMEOUT
9 MANUAL TIMEOUT
3 MODE SELECTION
1 SPEAKER ENABLE
ENABLE
DISABLE
2 BUSY CH LOCKOUT
ENABLE
DISABLE
3 REMOTE PAGING
ENABLE
DISABLE
4 CALL FORWARDING
ENABLE
DISABLE
5 AUTOPATCH TIMER
0 = PATCH DISABLED
10 MINUTES = DEFAULT
6 VOICE PROMPTS
ENABLE
DISABLE
7 WARMUP SIGNAL
ENABLE
DISABLE
4 TRANSCEIVER
1 TX SETUP
1 TX FREQUENCY
{464.5 MHZ}
2 TX SIGNALING
1 (CARRIER ONLY)
2 CTCSS
3 TX BANDWIDTH
NARROW BAND
WIDE BAND
2 RX SETUP
1 RX FREQUENCY
{464.5 MHZ}
2 RX SIGNALING
1 (CARRIER ONLY)
2 CTCSS
3 INVERT CARRIER DETECT
YES
NO
4 INVERT TRANSMIT DATA
YES
NO
5 TX TYPE
NO TYPE SELECTED
VHF
UHF
260 MHZ
5 CW CALL SIGN
{ DEFAULT = NONE }
6 DIAGNOSTIC MODE
(See Diagnostic Mode below )
4
F1 TOGGLE PHONE CONNECTION
DISCONNECTED
CONNECTED
F2 TOGGLE RADIO CONNECTION
DISCONNECTED
RECEIVE MODE
TRANSMIT MODE
F3 CONNECT MICROPHONE
DISCONNECTED
CONNECTED
F4 TOGGLE SPEAKER CONNECTION
DISCONNECTED
CONNECTED
1 PAGER BIT TEST
512 BAUD
1200 BAUD
2400 BAUD
2 SOUND TEST
(Press number or arrow keys)
3 DTMF TESTS
(UP ARROW key selects mode)
ENCODER TEST MODE
DECODER TEST MODE
ENCODER BEEP MODE
ENCODER LOW TONE
ENCODER HIGH TONE
4 DAC RAMP TEST
5 LCD TESTS
6 KEYPAD & KEYBOARD TESTS
7 ALARM INPUTS
8 FIRMWARE VER
Diagnostic Mode
(Menu item 6 from the Configuration Mode)
Note: Factory configuration defaults are indicated in bold type.
System Configuration
(Key 1 held down during power-up)
PASSWORD - 1590
Note: Factory configuration defaults are indicated in bold type.
RELEASED Version ©Toro 2006-2006
