g018656
Figure15
1.Shortrod
2.Longchutecontrolrod
4.Insertthefrontendoftherodintotheopeningin
thebackofthechutegearcoveruntilitslidesintothe
chutegear(Figure16).
Figure16
5.Aligntheholesinthenestedendsoftherodsand
insert2carriagebolts(intheloosepartsbag)through
theshortrodfromtheleftsideofthemachine(from
theoperatingposition).
6.Insertthecableclipthatsupportsthedeectorcable
undertheheadoftheforwardcarriagebolt,andsecure
thecarriageboltswithlocknutsfromthelooseparts
bag(Figure17).
g018657
Figure17
1.Cableclip2.Deectorcable
7.HoldthebluetriggercapdownandrotatetheQuick
Stickinacircletoensurethatthechuteanddeector
operatesmoothly.
5
ConnectingtheWiretothe
Headlight
Partsneededforthisprocedure:
1
Cabletie
Procedure
1.Insertthewireconnectoronthelooseendofthewire
straightintothebackoftheheadlightuntilitissecurely
inplace(Figure18).
1
2
3
G016761
Figure18
1.Plasticcliponwire
connector
3.Cabletie
2.U-bolt
Note:Ensurethattheplasticcliponthewire
connectorisonthebottom(Figure18).
2.Secureacabletie(fromtheloosepartsbag)aroundthe
wireandthehandleaboutaninch(2.5cm)belowthe
U-bolt(Figure18).
11
