Figure52
2.Loosentheboltonthecableclamp(Figure53).
Figure53
1.Cableconduit2.Cableclamp
3.Graspthecableconduitandmoveittowardthefront
ofthemachineuntilthedischargechutelatchfully
engagesthegearteeth(Figure53andFigure54).
Figure54
1.Dischargechutelatch
2.Gearteeth
Note:Thelatchisspringloadedandwillnaturally
moveintotheteethofthegear(Figure54).
4.Removeanyslackinthecablebypullingthecable
conduitrearward.
5.Tightentheboltonthecableclamp,beingcarefulnot
tostriptheplasticpart.
6.Installandsecurethegearcover.
ReplacingtheDriveBelts
Iftheauger/impellerdrivebeltorthetractiondrivebelt
becomesworn,oil-soaked,orotherwisedamaged,havean
AuthorizedServiceDealerreplacethebelt.
ReplacingtheHeadlightBulb
UseaGE89937Whalogenlightbulb.Donottouchthe
bulbwithyourhandsorallowdirtormoisturetocomeinto
contactwiththebulb.
1.Removethewireconnectorfromthebackofthe
headlight(Figure55).
Figure55
2.Turnthebaseofthebulbcounterclockwiseuntilit
stops(Figure56).
Figure56
3.Removethebulbstraightoutfromthebackofthe
headlight(Figure57).
Figure57
4.Insertanewbulbintothebackoftheheadlight
(Figure58).
