Toro power max 1028 - Initial Setup Steps; Installing the Upper Handle; Connecting Wheel Clutch Cables

1
InstallingtheUpperHandle
Partsneededforthisprocedure:
4Handlebolts
4
Curvedwashers
4Locknuts
Procedure
Note:Donotremovetherubberbandonthecablesuntil
youhaveinstalledtheupperhandle.
1.Liftandrotatetheupperhandleandpositionitover
thelowerhandle(Figure4).
Important:Routethecablesattachedtothe
QuickStickinsidetheupperhandlelegsand
ensurethatthecablesandthewireforthe
headlightarenotpinchedbetweenthehandle
sections.
Figure4
1.Cables
2.Securetheupperhandlewith4handlebolts,4curved
washers,and4locknutsfromtheloosepartsbag
(
Figure5).
Figure5
2
InstallingtheWheelClutch
CableEnds
NoPartsRequired
Procedure
1.Unwrapthecableendsfromthelowerhandle
(Figure6).
Figure6
2.Routeeithertheleftorrightcableendoverthelower
handleandinsertthecableendintotheholeinthe
correspondingwheelclutchlever(Figure7).
8
