Toro Power Max 1428 OHXE - Checking the Auger-Gearbox-Oil Level; Changing the Engine Oil

g260109
Figure27
1.Jamnut2.Turnbuckle
6.Loosenortightentheturnbucklethatadjuststhe
tensiononthecable(Figure27).
7.Adjusttheturnbuckleuntilyouobtaintheproper
gap.
8.Tightenthejamnut.
9.Insertthe2screwsthatyoupreviouslyremoved
onthebeltcover.
10.Iftheauger/impellercableisproperlyadjusted
butaproblemremains,contactanAuthorized
ServiceDealer.
Checkingthe
Auger-Gearbox-OilLevel
ServiceInterval:Yearly—Checktheauger-gearbox
oilandaddoilifnecessary.
1.Movethemachinetoalevelsurface.
2.Cleantheareaaroundthepipeplugandremove
thepipeplugfromthegearbox(Figure28).
Note:Ifneeded,useplierstoassistinremoving
thepipeplug.
g257725
Figure28
3.Checktheoillevelusingasuitablemeasuring
device,suchasacleancabletie.Theoilshould
beapproximately3.8cm(1.5inches)belowthe
lleropening(Figure29).
g257737
Figure29
4.Iftheoillevelislow,addGL-5orGL-6,SAE
85-95EPgearoillubricanttothegearbox,then
checktheoillevelagain.
Note:Donotusesyntheticoil.
5.Installthepipepluginthegearbox.
ChangingtheEngineOil
ServiceInterval:Aftertherst5hours—Changethe
engineoil.
Yearly—Changetheengineoil.
Ifpossible,runtheengineforafewminutesbefore
changingtheoilbecausewarmoilowsbetterand
carriesmorecontaminants.
Engineoilcapacity
1.10L(37oz)
OilviscosityRefertoFigure30.
APIserviceclassicationSJorhigher
UseFigure30belowtoselectthebestoilviscosityfor
theoutdoortemperaturerangeexpected:
19
