Toro Recycler User Manual

FoldingtheHandle
WARNING
Foldingorunfoldingthehandleimproperly
candamagethecables,causinganunsafe
operatingcondition.
•Donotdamagethecableswhenfoldingor
unfoldingthehandle.
•Ifacableisdamaged,contactan
AuthorizedServiceDealer.
1.Removetheelectric-startbuttonasshownin
Figure22(electric-startmodelonly).
g035929
Figure22
1.Electricstarter2.Electric-startbutton
2.Removeandsavethe2handleknobsand2
carriageboltsfromthehandlebrackets(Figure
23).
Important:Routethecablestotheoutside
ofthehandleknobsasyoufoldthehandle.
g032869
Figure23
1.Handleknob(2)2.Carriagebolt(2)
3.Foldthehandlebyrotatingitforward(Figure24).
g032870
Figure24
1.Operatingposition
2.Foldedposition
4.Insertthecarriagebolt(withtheboltheadtoward
theinside)throughthehandlebracketandthe
upperholeinthehandleend.Ensurethatthe
squareedgesofeachcarriagebolttsintothe
upperorlowersquareholeinitsrelatedhandle
bracket(Figure25).
19
