ReplacingtheFuse
ForElectric-StartModels
Ifthebatterydoesnotchargeortheenginedoesnot
runwiththeelectricstarter,thefusemaybeblown.
Replaceitwitha40Aplug-intypefuse.
1.Raisethereardeectorandlocatethebattery
compartment(Figure31).
g009506
Figure31
1.Reardeector
3.Battery
2.Screw
4.Batterycompartment
2.Wipeawayanydebrisfromthebattery
compartmentarea.
3.Removethescrewthatsecuresthebattery
compartment,pulloutthebattery,andlocatethe
fuse(Figure32).
g030022
Figure32
1.Cover
3.Fuse
2.Fuseholder
4.Replacethefuseinthefuseholder(Figure32).
Note:Yourmachinecomeswithasparefusein
thebatterycompartment.
5.Installthebatterycompartmentwiththescrew
thatyouremovedinstep3.
6.Installthecoveroverthebatterycompartment.
7.Lowerthereardeector.
