InstallingtheSparkPlug
g028109
Figure21
CleaningtheEngineScreen
ServiceInterval:Beforeeachuseordaily
Beforeeachuse,removeanybuildupofgrass,
dirt,orotherdebrisfromtheenginescreen.This
helpsensureadequatecoolingandcorrectengine
speedandreducesthepossibilityofoverheatingand
mechanicaldamagetotheengine.
g242388
Figure22
FuelSystem
Maintenance
CleaningtheSedimentCup
ServiceInterval:Every100hours
Yearlyorbeforestorage
Underneaththefuelvalveisasedimentcuptocatch
dirtinthefuel.
1.Parkthemachineonalevelsurfaceandengage
theparkingbrake.
2.Shutofftheengineandwaitforallmovingparts
tostop.
3.MovethefuelvalvetotheOFFposition,allthe
waytotheleft.
4.Unscrewthesedimentcup(Figure23).
g014507
Figure23
1.Sedimentcup2.O-ring
5.CleanthereservoirandtheO-ringusinga
cleaningsolventanddrycarefully.
Note:MakesurenottomisplacetheO-ring.
6.PlacetheO-ringinthegrooveofthecupand
replacethesedimentcup.
7.TurnthefuelvalvetotheONposition,alltheway
totheright,andcheckforleaks.
Note:Ifitleaks,replacetheO-ring.
