5.Removethelterfromthefuellines.
6.Installanewlterandmovethehoseclamps
closetothelter.
7.Turnthefuel-shutoffvalvetotheopenposition.
8.Checkforfuelleaksandrepairifneeded.
9.Wipeupanyspilledfuel.
Servicingthe
High-PressureFuelFilter
Donotattempttoservicethehigh-pressurefuel
lter.Thehigh-pressurelterisintegratedwithin
thefuel-pumpmodule.Thefuellterandother
componentsinsidethefuel-pumpmodulearenot
serviceable.
Important:Donotattempttoopenthefuel-pump
module.
EnsurethatanAuthorizedServiceDealerreplaces
thefuel-pumpmodulewiththehigh-pressurefuellter.
ElectricalSystem
Maintenance
ServicingtheBattery
ServiceInterval:Every25hours—Checkthebattery
electrolytelevel.
Alwayskeepthebatterycleanandfullycharged.Use
apapertoweltocleanthebatterycase.Ifthebattery
terminalsarecorroded,cleanthemwithasolutionof
4partswaterand1partbakingsoda.Applyalight
coatingofgreasetothebatteryterminalstoreduce
corrosion.
Voltage:12Vwith350A(coldcranking)at-18°C
(0ºF).
WARNING
Incorrectbatterycableroutingcoulddamage
themachineandcables,causingsparks.
Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
•Alwaysdisconnectthenegative(black)
cablebeforedisconnectingthepositive
(red)cable.
•Alwaysconnectthepositive(red)cable
beforeconnectingthenegative(black)
cable.
WARNING
Batteryterminalsormetaltoolscouldshort
againstmetalcomponents,causingsparks.
Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
•Whenremovingorinstallingthebattery,
donotallowthebatteryterminalstotouch
anymetalpartsofthetractionunit.
•Donotallowmetaltoolstoshortbetween
thebatteryterminalsandmetalpartsofthe
tractionunit.
29
