Toro STX-38 - Checking the Hydraulic-Fluid Level; Replacing the Hydraulic Filter; Changing the Hydraulic Fluid

issufcientfor15to22L(4to6USgallons)
ofhydraulicoil.OrderPart44-2500fromyour
AuthorizedServiceDealer.
Checkingthe
Hydraulic-FluidLevel
ServiceInterval:Every25hours
RefertoHydraulicFluidSpecications(page37)for
hydraulicuidspecications.
1.Parkthemachineonalevelsurface,engage
theparkingbrake(ifapplicable),andlowerthe
hydrauliclift.
2.Shutofftheengineandremovethekey.
3.Lookintotheglassbubbleontherightsideof
themachine.Ifyoucannotseehydraulicuidin
thebubble,continuethisproceduretoadduid.
g019839
Figure59
1.Hydraulic-uidcheckbubble
4.Removethecoverplate;refertoRemovingthe
FrontCover(page21).
5.Cleantheareaaroundthellerneckofthe
hydraulictankandremovethecapandlter
fromthellerneckusingasocket(Figure60).
g019840
Figure60
1.Filler-neckcap
2.Hydraulic-uidlter
6.Ifthelevelislow,adduiduntilitisvisibleinthe
glassbubble.
7.Installthecapandlteronthellerneckand
torqueboltontopto21to25N∙m(200to240
in-lb).
8.Installthecoverplate;refertoRemovingthe
FrontCover(page21).
ReplacingtheHydraulic
Filter
ServiceInterval:Every200hours
1.Parkthemachineonalevelsurface,engage
theparkingbrake(ifapplicable),andlowerthe
hydrauliclift.
2.Shutofftheengineandremovethekey.
3.Removethetopcover.
4.Removeanddiscardtheoldlter(Figure61).
g019840
Figure61
1.Fillercap
2.Hydrauliclter
5.Installthereplacementhydrauliclterandller
cap(Figure61)andtorquetheboltontopto21
to25N∙m(200to240inch-lb).
6.Cleanupanyspilleduid.
7.Installthetopcover.
ChangingtheHydraulic
Fluid
ServiceInterval:Every400hours/Yearly(whichever
comesrst)
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,andlowerthehydrauliclift.
2.Shutofftheengineandremovethekey.
3.Allowthemachinetocoolcompletely.
4.Removethetopcover.
5.Removethehydraulic-tankllercapandlter
(Figure61).
38
