Figure
3
1. Rope
guide
2.
Starter rope
Note: T
o make the rope easier to loop, squeeze the control
bail on the handle to release the blade brake.
Assembling
the Mower
Self
Pr
opelled Models Only
Unpacking the Mower
IMPORTANT:
Be extr
emely car
eful when unpacking
and handling the mower and upper handle so that you
do not pull, crimp, or in any way damage the cables.
1.
Open the box from the top.
2.
Remove the fillers from the box, allowing the upper
handle to rest on the top of the mower
.
3.
Remove the mower from the box.
4.
Lay the upper handle on the ground behind the mower
with the handle label facing up and the control cables
routed between the handle mounting brackets.
Assembling the Handle
1. Remove
the four handle bolts and knobs that are
installed in the lower handle (two bolts will have flat
caps and two will be contoured to fit the handle).
2.
Swing the lower handle back and the support brackets
up, aligning the brackets with the holes in the handle
(Fig. 4).
3.
Secure the handle to the support brackets with the two
flat handle bolts and two knobs, using the height
adjustment holes on the brackets that best suit your
height requirements (Fig. 4)
m–4272
2
1
4
3
Figure
4
1. Lower
handle
2.
Support bracket
3. Knob
4.
Flat handle bolt
IMPORTANT:
Use car
e to prevent pinching or
str
etching the cables.
Note:
If handle height is not satisfactory
, adjust it by
installing the handle bolt and knob through a dif
ferent set
of holes.
4.
Slide the upper handle section ends over the lower
handle so that the sections nest together (Fig. 5)
5.
Ensure that the cables are routed below/behind the
lower handle as illustrated in Figure 5.
6.
Secure the upper handle to the lower handle using two
contoured handle bolts and two knobs (Fig. 5).
5
m–4204
3
2
4
1
5
Figure
5
1. Cables
2. Lower
handle
3.
Upper handle
4.
Contoured handle bolt
(only one shown)
5. Knobs
