Operation
Starting the Engine
1. Push the primer three times (five times if the
temperature is 13 _C/55_ F or below), waiting 2
seconds between each push (Fig. 10).
IMPORTANT : Do not use the primer to r estart a
warm engine.
m-3855
1
Figure
10
1. Primer
2. Hold the blade control bail against the upper handle
(Fig. 1 1).
m-4207
3
2
1
m-3712
1
3 2
Hand Push Models Self–propelled Models
Figure 1 1
1. Blade control bail
2. Upper handle
3. Starter handle
3. Start the mower .
•
Manual Starting –Pull the starter handle lightly
until resistance is felt, then pull it sharply (Fig. 1 1).
Allow the rope return to the handle slowly .
•
Key-lectric Starting (Electric start models
only) –Insert the key into the switch. T urn the key
to the right and release it when the engine starts
(Fig. 12).
Note: If the battery char ge is too low to start the
engine, start the engine with the recoil starter .
Figure 12
Note: If the engine fails to start after three attempts,
repeat steps 1–3.
Stopping the Engine
Release the blade control bail. Both the engine and blade
will stop. See your dealer immediately if they do not.
Self–propel Drive
Self-propelled Models Only
T o operate the self-propel drive, simply walk forward with
your hands on the upper handle. As you move forward,
the upper handle will slide toward the mower
, activating
the self–propel drive. The faster you walk, the farther the
handle will slide and the faster the mower will propel
(Fig. 13).
Note: The mower propels at the maximum speed when the
upper handle is pushed as far forward as possible.
T o slow down or stop, simply slow your walking speed or
stop (Fig. 13). If, when backing up after
self–pr opelling, the mower does not r oll backward
freely , nudge the mower forward about an inch without
engaging the self–pr opel drive, then pull the mower
backward.
m–4206
Figure 13
