Toro TimeCutter 5000 Operator's Manual

CAUTION
Ifyouleavethekeyintheswitch,someonecouldaccidentlystarttheengineandseriously
injureyouorotherbystanders.
Shutofftheengineandremovethekeyfromtheswitchbeforeyouperformanymaintenance.
Pre-Maintenance
Procedures
RaisingtheMachine
Usejackstandstosupportthemachinewhenyou
raiseit.
WARNING
Supportingthemachineonthelowermufer
shield(Figure28)maydamagetheshieldand
causethemachinetofall,injuringyouor
bystanders.
Donotusethelowermufershieldtosupport
themachine.
g299647
Figure28
1.Lowermufershield
Lubrication
GreasingtheBearings
ServiceInterval:Every25hours—Greasethecaster
wheelbearings.
GreaseType:No.2lithiumgrease
1.Parkthemachineonalevelsurface,disengage
theblade-controlswitch,andmovethe
motion-controlleversoutwardtothePARK
position.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Cleanthegreasettings(Figure29)witharag.
Note:Scrapeanypaintoffthefrontofthe
tting(s).
g032432
Figure29
1.Frontcastertire
4.Connectagreaseguntoeachtting(Figure29).
5.Pumpgreaseintothettingsuntilgreasebegins
tooozeoutofthebearings.
6.Wipeupanyexcessgrease.
27
