FuelSystem

Maintenance

DANGER

Incertainconditions,fuelisextremely

ammableandhighlyexplosive.Areor

explosionfromfuelcanburnyouandothers

andcandamageproperty.

RefertoFuelSafety(page12)foracomplete

listoffuelrelatedprecautions.

ReplacingtheIn-LineFuel

Filter

ServiceInterval:Every100hours—Replacethe

in-linefuellter.

Neverinstalladirtylterafterremovingitfromthe

fuelline.

1.Parkthemachineonalevelsurface,disengage

theblade-controlswitch,andmovethe

motion-controlleversoutwardtothePARK

position.

2.Shutofftheengine,removethekey,andwait

forallmovingpartstostopbeforeleavingthe

operatingposition.

g305646

g033082

Figure40
