DeckLiftAssembly3PointRemoval(continued)
g301969
Figure196
21.Removethe2screwssecuringthebellcrankretentionbrackettothechassis.
Repeatforoppositeside.
g301970
Figure197
DeckLiftAssembly3PointInstallation
1.Installthe2screwssecuringthebellcrankretentionbrackettothechassis.
Repeatforoppositeside.Torquescrewsto17–22.5N•m(150–200in-lb).
Chassis:ServiceandRepairs
Page5–90
TIMECUTTER®ServiceManual
3433-938RevA
