Toro TimeCutter SS3225 User Manual

g014973
Figure50
1.Blade(inpositionformeasuring)
2.Levelsurface
3.Measureddistancebetweenbladeandthesurface(A)
4.Rotatethesameblade180degreessothat
theopposingcuttingedgeisnowinthesame
position(Figure51).
g014974
Figure51
1.Blade(sidepreviouslymeasured)
2.Measurement(positionusedpreviously)
3.Opposingsideofbladebeingmovedintomeasurement
position
5.Measurefromthetipofthebladetotheat
surface(Figure52).
Note:Thevarianceshouldbenomorethan
3mm(1/8inch).
g014973
Figure52
1.Oppositebladeedge(inpositionformeasuring)
2.Levelsurface
3.Secondmeasureddistancebetweenbladeandsurface(B)
A.IfthedifferencebetweenAandBisgreater
than3mm(1/8inch),replacethebladewith
anewblade;refertoRemovingtheBlades
(page44)andInstallingtheBlades(page
45).
Note:Ifabentbladeisreplacedwitha
newblade,andthedimensionobtained
continuestoexceed3mm(1/8inch),the
bladespindlecouldbebent.Contactan
AuthorizedServiceDealerforservice.
B.Ifthevarianceiswithinconstraints,moveto
thenextblade.
6.Repeatthisprocedureoneachblade.
RemovingtheBlades
Thebladesmustbereplacedifasolidobjectishit,if
thebladeisoutofbalance,orifthebladeisbent.For
bestperformanceandcontinuedsafetyconformance
ofthemachine,usegenuineTororeplacementblades.
Replacementbladesmadebyothermanufacturers
mayresultinnon-conformancewithsafetystandards.
1.Holdthebladeendusingaragorthickly-padded
glove.
2.Removethebladestiffener(32-inchdecksonly),
bladebolt,thecurvedwasher,andtheblade
fromthespindleshaft(Figure53andFigure54).
44

Toro TimeCutter SS3225 Specifications

General

Engine Displacement	452cc
Engine Brand	Toro
Cutting Width	32 inches
Transmission	Hydrostatic
Blade Quantity	2
Deck Material	Steel
Cutting Height	1.5 - 4.5 inches
Fuel Capacity	3 gallons
