A1-12 TimeCutter ZX Service Manual
1b
Specifi cations cont.
ZX 18-44 ZX 440
Engine: 18 hp Briggs & Stratton OHV, 31M777 18 hp Kohler® OHV, CV492S
High Idle 3400 + 100 RPM 3400 + 50/- 0 RPM
Low Idle 1400 RPM 1400 RPM
Horse Power 18 (13.4kW) @3600 RPM 10 HP (13.4kW) @ 3600 RPM
Cubic Centimeter’s (cc’s) 500 Displacement 490 Displacement
Fuel Unleaded Gasoline 87 octane min. Unleaded Gasoline 87 octane min.
Oil Capacity 1.75 qts. (1.7 L) 2 qts. (1.9 L)
Charge coil 12v - 16 amp 12v - 15 amp
Construction:
Front Frame Welded 1x2x.120” structural steel tube Welded 1x2x.120” structural steel tube
Rear Frame Welded 7 & 10 ga. High strength steel Welded 7 & 10 ga. High strength steel
Frame Assembly Front & rear frames bolted together. Front & rear frames bolted together.
Deck Right side discharge, 44” cut, three blade
mid-mounted rotary. Drawn 13 gauge
steel with welded mounting brackets and
gauge wheel brackets. Frame supported.
Right side discharge, 44” cut, three blade
mid-mounted rotary. Drawn 13 gauge
steel with welded mounting brackets and
gauge wheel brackets. Frame supported.
Fuel System: Single fuel tank fender type mounted on
the left side.
Single fuel tank fender type mounted on
the left side.
Capacity 5 Gallons (18.9 L)
Fuel tank shut off
In-line fuel fi lter
5 Gallons (18.9 L)
Fuel tank shut off
In-line fuel fi lter
Traction System:
Transaxles Twin Hydro-Gear IZT Hydrostatic
Transaxles
Twin Hydro-Gear IZT Hydrostatic Trans-
axles with charge pumps & shock valves
Transaxle Drive Belt Drive with self-tensioning system Belt Drive with self-tensioning system
Ground speed forward Infi nite, 0 to 6.5-MPH (10.5-km/hr) Infi nite, 0 to 7.0-MPH (11.3-km/hr)
Ground speed reverse 0 to 3.4-MPH (5.5-km/hr) 0 to 3.4-MPH (5.5-km/hr)
Transport rods Allows unit to be moved without engine
running.
Allows unit to be moved without engine
running.
Attachment Drive:
Clutch Electric Electric
Type Vertical Drive with Single Deep B-Groove
Pulley
Vertical Drive with Single Deep B-Groove
Pulley
SPECIFICATIONS
To Next Page
