6 - 20 TimeCutter™ Z Service Manual
CHASSIS
6
Disconnect the electrical connection for the PTO
clutch.
Remove the mower deck drive belt from the left
side pulley and clutch pulley.
Place the rear of the unit on jack stands.
Remove the PTO clutch bolt and the electric
clutch assembly.
0702-0411
0702-0417
0702-0631
Replace Traction Belt
